Designed to meet the demands of improving rigsite efficiency, improving manual handling operations whilst reducing carbon emissions and costs, the EnerQuip Mobile Torque Unit (MTU) delivers a package that is unrivaled.
Capable of making up casing range 3 doubles and drill pipe triples automatically and delivering an output of up to 20 casing doubles an hour. This output can deliver as much as a 45% rig time saving over conventional operations.
The system requires only one person to oversee all bucking operations and feed connections to a waiting catwalk for delivery to the drill floor. This reduces manpower allowing them to be repurposed in other areas of the operation.
Key Features
- Developed in 2021 and deployed to the Middle East for rig side mobile torque makeup of drill pipe and casing
- Capable of making up range 3 casing doubles and drill pipe triples
- Able to run fully automated, reducing manpower and improving safety and efficiency
- Clamp range from 2.3/8” to 22”
- Torque capable up to 130,000 ft.lbs
- Ability to be operational in under 4 hrs from equipment arriving onsite
- Climate controlled operator cabin
- Can be paired with any manufacturers catwalk for delivery of casing and drilpipe to drill floor
- Capable of rig side teardown of drill string components, and BHA makeup
